MCN-1003-0109

  • MCN-1003-0109
  • MCN-1003-0109
Description
Pin Header. 1.27mm, 2*10 Pins, 90 Deg., SMD
PREV PRO. Inquiry NEXT PRO.
  • Product Specification



SPECIFICATIONS

  • Contact Current Rating ：3 Amp
  • Contact Resistance ： 20 mΩ Max
  • Insulator Resistance ： 5,000 MΩ Min
  • Dielectric Withstanding Voltage： 500V AC RMS 60 Seconds

MECHANICAL

  • Insulator ： Nylon-6T, UL 94V-0
  • Contact ： Brass
  • Contact Plated： Gold Plated、Tin Plated
  • Operation Temperature ：- 40℃ to + 105℃
